DIN 927 - Slotted Shoulder Screws
Thread size d
|
M1
|
M1.2
|
M1.4
|
M1.6
|
M2
|
M2.5
|
M3
|
M(3.5)
|
M4
|
M5
|
M6
|
|
P
|
0.25
|
0.25
|
0.3
|
0.35
|
0.4
|
0.45
|
0.5
|
0.6
|
0.7
|
0.8
|
1
|
|
b
|
min.= nominal size
|
1.8
|
1.8
|
2.2
|
2.5
|
2.8
|
3.5
|
4.5
|
5.5
|
6
|
7
|
8
|
max.
|
2.05
|
2.05
|
2.45
|
2.75
|
3.05
|
3.8
|
4.8
|
5.8
|
6.3
|
7.36
|
8.36
|
|
dk
|
max. = nominal size
|
1.6
|
1.8
|
2
|
2.2
|
2.8
|
3.5
|
4
|
4.5
|
5.5
|
6.5
|
8
|
min.
|
1.575
|
1.775
|
1.975
|
2.175
|
2.775
|
3.47
|
3.97
|
4.47
|
5.47
|
6.464
|
7.964
|
|
f max.
|
0.2
|
0.2
|
0.25
|
0.3
|
0.4
|
0.5
|
0.5
|
0.7
|
0.8
|
0.8
|
1
|
|
n
|
Nominal size
|
0.2
|
0.25
|
0.25
|
0.3
|
0.3
|
0.4
|
0.5
|
0.5
|
0.6
|
0.8
|
1
|
min.
|
0.26
|
0.31
|
0.31
|
0.36
|
0.36
|
0.46
|
0.56
|
0.56
|
0.66
|
0.86
|
1.06
|
|
max.
|
0.4
|
0.45
|
0.45
|
0.5
|
0.5
|
0.6
|
0.7
|
0.7
|
0.8
|
1
|
1.2
|
|
t
|
min.
|
0.4
|
0.4
|
0.48
|
0.56
|
0.64
|
0.72
|
0.8
|
0.96
|
1.12
|
1.28
|
1.6
|
max.
|
0.52
|
0.52
|
0.63
|
0.74
|
0.64
|
0.95
|
1.05
|
1.21
|
1.42
|
1.63
|
2
|
|
