DIN 479 - Square Head Bolts

DIN 479 - Square Head Bolts



d
M5
M6
M8
M10
M12
M16
M20
M24
P
0.8
1
1.25
1.5
1.75
2
2.5
3
a1 max
2.4
3
4
4.5
5.3
6
7.5
9
dp
max=Nominal Dimension
3.5
4
5.5
7
8.5
12
15
18
min
3.32
3.82
5.32
6.78
8.28
11.73
14.73
17.78
e
max=Nominal Dimension
6.5
8
10
13
17
21
22
27
28
32
min
5.92
7.42
9.42
12.3
16.3
20.16
21.16
26.16
27.16
31
k
Nominal Dimension
5
6
8
10
12
16
20
22
min
4.85
5.85
7.82
0.82
11.79
15.79
19.74
21.74
max
5.15
6.15
8.18
10.18
12.21
16.21
20.26
22.26
k'
min
3.4
4.1
5.5
6.9
8.3
11.1
13.8
15.2
r
min
0.2
0.25
0.4
0.4
0.6
0.6
0.8
0.8
s
max
5
6
8
10
13
46
17
21
22
24
min
4.82
5.82
7.78
9.78
12.73
15.73
16.73
20.67
21.67
23.67
z1
min
1.25
1.5
2
2.5
3
4
5
6
max
1.5
1.75
2.25
2.75
3.25
4.3
2.3
6.3
